PRE-OWNED EQUIPMENT & PARTS

Used microscopes refurbished for years of trouble free use. All used microscopes are cleared, serviced to factory specs and worn parts are replaced. We guarantee it. Used microscopes from Nikon, Leica, Meiji, Olympus, Mitutoyo, Bausch & Lomb, Cambridge Instruments, Zeiss and more. Metallurgical Microscope, Stereozoom Microscope, Student Microscope, Clinical Microscope. We also carry used precision measuring and gauging equipment. LOW PRICE BLOWOUT SEE SALE ITEMS BELOW. Priced hundreds, thousands below other dealers. No BS, just low prices.

1 year performance guarantee on all microscopes.

Microscope Service consists of Exterior Cleaning, Internal Cleaning, Lubrication, Zoom adjustment, Parfocalized, Resolution adjustment, and Centration of fields of view all to factory specs or better.  Worn parts are replaced.

Bausch & Lomb StereoZoom 7 Replacement Pods 1x to 7x magnification. Eyepieces, objective lenses, stands, cameras and illuminators are available.
Olympus and Nikon Replacement Pods  In excellent condition. SZ 4045, SZ 6045, SZ 3060, SZ 4060, SZM 1B . Eyepieces, objective lenses, stands, cameras and illuminators are available.
Bausch & Lomb Stereo Zoom 4 Replacement Pods  In excellent condition fully serviced and ready for work. 100mm working distance. 0.7x to 3x magnification. Eyepieces, objective lenses, stands, cameras and illuminators are available to configure for your needs. Ask our experts for information.
Nikon CFUW10x/25 Ultra Wide Eyepiece Pair    $300,  new list price on these is $800. Half the new price for a really great pair of eyepieces. Super flat field of view. Excellent condition. with eyecups. 30mm barrel, focusing design with reticle mounts. Will fit most all 30mm tube microscopes Some of the best eyepieces ever made.
B&L 15x/20 Ultra wide Eyepiece Pair    $375,  new list price on these is $750. Half the new price for the best 15x view there is. These have such a nice deep, flat field of view right to the edge. Excellent condition. We also have new from a contract manufacture for $575 per pair. Standard DIN 23.2mm eyepiece tubes.
Aus Jena ( Zeiss ) Laboval microscope. $599 Top quality microscope in new condition. 3.2x, 10x, 40x, and Plan 100x oel objectives. 1.2 Abbe phase condenser with iris diaphragm, flip out low mag condenser lens. (No phase sliders). Rack and pinion condenser stage. Graduated coaxial XY left hand drive stage with slide clamp. Coaxial graduated course/fine (1 micron) focus controls. Built in 6volt 20watt halogen variable intensity illuminator. P10x/18 wide field eyepieces with machined aluminum eye cups. Focus correction ring on left eye tube. 50-75 diopter adjustment. Don't miss this deal. Beautiful!!
Zeiss Stemi SV-11 Stereozoom microscope. $4088 This is one fine microscope to own. Top of the Zeiss line. 1x plan S objective lens. Plan 10x/25 adjustable eyepieces. .60x to  6.6 (11:1) Zoom. Has iris diaphragm for excellent depth of field viewing. Huge flat field of view. Nothing like it. Comes with Schott / Zeiss KL 1500 Illuminator. Built in Filter holder, diffuser lens with in and out, separate power switch and light intensity. Zeiss fiber optic ring light.  Pivoting drop post on a really nice ball bearing boom stand with beautiful locks etc... Can't beat this setup.
Olympus SZ 3060 Stereozoom  Microscope. $1088 Comes on a B&L boom stand with Olympus 10x wide field eyepieces, STB-1 focus mount, 9x to 40x magnification. Additional objective lenses available. Illuminators sold separately. Available new and used, fluorescent ring lights, fiber optic, ring and dual light pipe. We have many Olympus microscopes in stock.
Meiji EMZ-5 Stereozoom Microscope  $1088 Excellent original condition, fully serviced with 1 year guarantee. 3.5x to 45x magnification. 150mm working distance with the included .5x objective lens. 100mm working distance when removed. SWF 10x23 eyepieces. Dual diopter, focus on eyepiece tubes. Fully adjustable Meiji boom stand with rack and pinion focus mount. Large field of view. Solid construction. Very dependable.
Olympus SZ 4045 Stereozoom  Microscope. $1288 Comes on an Olympus boom stand with Olympus 10x wide field eyepieces, STB-1 focus mount, 10x to 40x magnification. Additional objective lenses available. Illuminators sold separately. Available new and used, fluorescent ring lights, fiber optic, ring and dual light pipe. We have many Olympus microscopes in stock.
Meiji EMZ-5 Stereozoom Microscope  $1088 Excellent original condition, fully serviced with 1 year guarantee. 3.5x to 45x magnification. 150mm working distance with the included .5x objective lens. 100mm working distance when removed. SWF 10x23 eyepieces. Dual diopter, focus on eyepiece tubes. Fully adjustable Meiji boom stand with rack and pinion focus mount. Large field of view. Solid construction. Very dependable.
Olympus SZ 4045ESD Stereozoom  Microscope. $1388 Comes on a Diagnostic Instruments boom stand with Olympus 10x wide field eyepieces, STB-1 focus mount, 6.7x to 45x magnification. Additional objective lenses available. Illuminators sold separately. Available new and used, fluorescent ring lights, fiber optic, ring and dual light pipe. We have many Olympus microscopes in stock.
Olympus SZ 4060 Stereozoom  Microscope. $1288 Comes on a Diagnostic Instruments boom stand with Olympus 10x wide field eyepieces, STB-1 focus mount, 6.7x to 45x magnification. Additional objective lenses available. Illuminators sold separately. Available new and used, fluorescent ring lights, fiber optic, ring and dual light pipe. We have many in Olympus microscopes in stock.
Olympus SZ 4045 Stereozoom  Microscope. $1288 Comes on a Diagnostic Instruments boom stand with Olympus 10x wide field eyepieces, STB-1 focus mount, 6.7x to 45x magnification. Additional objective lenses available. Illuminators sold separately. Available new and used, fluorescent ring lights, fiber optic, ring and dual light pipe. We have many Olympus microscopes in stock.
Olympus SZ 4045 Stereozoom  Microscope. $1188 Comes on an Olympus desktop stand, Olympus GSWH 10x/22 wide field eyepieces, 6.7x to 45x magnification. Additional objective lenses available. Illuminators sold separately. Available new and used, fluorescent ring lights, fiber optic, ring and dual light pipe. We have many Olympus microscopes in stock.
Olympus SZ 4045 Stereozoom  Microscope. $1188 Comes on an Olympus desktop stand, Olympus GSWH 10x/22 wide field eyepieces, 6.7x to 45x magnification. Additional objective lenses available. Illuminators sold separately. Available new and used, fluorescent ring lights, fiber optic, ring and dual light pipe. We have many Olympus microscopes in stock.
Olympus SZ 4045 ESD Stereozoom  Microscope. $1288 Comes on an Olympus desktop stand, Olympus GSWH 10x/22 wide field eyepieces, 6.7x to 45x magnification. Additional objective lenses available. Illuminators sold separately. Available new and used, fluorescent ring lights, fiber optic, ring and dual light pipe. We have many Olympus microscopes in stock.
Olympus SZ 4045 Stereozoom  Microscope. $1188 Comes on an Olympus desktop stand, Olympus GSWH 10x/22 wide field eyepieces, 6.7x to 45x magnification. Additional objective lenses available. Illuminators sold separately. Available new and used, fluorescent ring lights, fiber optic, ring and dual light pipe. We have many Olympus microscopes in stock.
Olympus SZ 1145 CHI Stereozoom  Microscope. $1988 Comes on an Olympus desktop stand, Olympus GSWH 10x/22 wide field eyepieces, 18x to 110x magnification. Vertical Illuminator with polarizer bottom lens. Additional objective lenses available. Illuminators sold separately. Available new and used, fluorescent ring lights, fiber optic, ring and dual light pipe. We have many Olympus microscopes in stock.
Olympus SZ 4045 Stereozoom  Microscope. $1288 Comes on an Olympus desktop stand and trans-illuminated base, Olympus GSWH 10x/22 wide field eyepieces, 6.7x to 45x magnification. Additional objective lenses available. Illuminators sold separately. Available new and used, fluorescent ring lights, fiber optic, ring and dual light pipe. We have many Olympus microscopes in stock.
Olympus SZ 3060 Stereozoom  Microscope. $1088 Comes on an Olympus desktop stand, Olympus GSW 10x/23 wide field eyepieces, 9x to 40x magnification. Additional objective lenses available. Illuminators sold separately. Available new and used, fluorescent ring lights, fiber optic, ring and dual light pipe. We have many Olympus microscopes in stock.
Olympus SZ 4060 Stereozoom  Microscope. $1188 Comes on an Olympus desktop stand, Olympus GSWH 10x/22 wide field eyepieces, 6.7x to 45x magnification. Additional objective lenses available. Illuminators sold separately. Available new and used, fluorescent ring lights, fiber optic, ring and dual light pipe. We have many Olympus microscopes in stock.
Leica Stereo Zoom 4 Microscope. $1330 Comes on a B&L boom stand, Chiu variable intensity fiber optic halogen ring light. 10x wide field B&L eyepieces, e-arm. 7x to 30x magnification. Can use other objective lenses to get 3.5x to over 100x magnification. We have other illuminators and lenses to configure as desired.
Leica Stereo Zoom 4 Microscope. $1188 Comes on a boom stand with a 10x wide field B&L eyepieces, e-arm and a Stocker & Yale ring light. 7x to 30x magnification. Can use other objective lenses to get 3.5x to over 100x magnification. We have other illuminators and lenses as desired. We have many in stock.
Bausch & Lomb Stereo Zoom 7 Microscope. $2188 Beautiful research microscope on the fabulous "R" model stand with a 4x4 stage. The stage can be rotated for low right hand drive or front left hand drive. Zoom 7 pod has built in variable intensity halogen 6v 20w vertical illuminator. 10x - 70x magnification. Optional objective lenses are available.
B&L Photo Port for Stereozoom 7 $389 attaches to the rear port of the stereozoom 7 microscope to provide photographic capability. Couplers available to attach 35mm, digital and video cameras.
Nikon SMZ-1B Stereo Zoom Microscope. $1288 A real beauty. These scopes are one of the best you can buy. Comes on a stock Nikon boom stand, with 10x wide field eyepieces. 8x to 35x magnification. Stocker & Yale ring light. You won't find many as good as this one....
American Optical Stereo Zoom Microscope. $588 Model 569 with 10x to 42x magnification with AO 10x widefield eyepieces all in excellent condition. Fully services and ready for work. Mounted on an AO desk stand. 100mm working distance. We have nicholas illuminators available for this unit. Can also be supplied with a fiber optic ring light or fluorescent ring light.
Bausch & Lomb Stereo Zoom 6 Plus. $1088 A real nice scope. 67x - 40x magnification. Super wide field 10x eyepieces offer superior field of view and a very sharp erect image. Adjustable zoom stops can be set to any position. 90mm working distance. Boom stand offers easy positioning for most all specimens.
B&L Stereo Zoom 4  $888 with 10x WF eyepieces and a Nicholas illuminator on an A stand all in excellent condition. 100mm working distance.  7x to 30x magnification. Additional lenses and eyepieces in 15x and 20x are available. Supplementary lenses in .3x, .5x, 2x are available.
B&L Stereo Zoom 4 $1189 with 10x WF eyepieces and a Nicholas illuminator on a KT base all in excellent condition. 100mm working distance. 7x to 30x magnification. Additional lenses and eyepieces in 15x and 20x are available. Supplementary lenses in .3x, .5x, 2x are available.
B&L Stereo Zoom 7 $1288 with 10x WF eyepieces and a Nicholas illuminator on a B stand all in excellent condition. 10x to 70x magnification. Additional lenses and eyepieces in 15x and 20x are available. Supplementary lenses in .5x, 2x are available.
B&L MicroZoom microscope $4988 (-$500 on sale)1x to 2x zoom body. Trinocular model with top port for camera. Cameras, video, stages, etc available. Several models to choose from. Beautiful scopes with course and fine focus. LWD objectives included 2.25x, 8x, 25x, and 50x. Provide up to 1000x magnification. Can be configured to customer needs.
Mitutoyo Toolmakers Microscope $4469 model TM 201 (176-311) with 3x objective and SW10x25 eyepieces. Digital readout .001mm/.00005" resolution. Inch/metric readout with direction and zero function. 2" travel electronic drum micrometer heads. 2x4 travel stage with glass top plate and angle adjustment. Top and bottom lighting with iris, green filters and eyepiece cross line reticle. 10x25 Super Widefield eyepieces give exceptional field of view. Halogen ring lights, surface lights available in stock. Can be configured to customer needs. SOLD
Nikon Optiphot 150 Binocular Brightfield / Darkfield Metallurgical Microscope On sale $5588.  I guarantee this is the lowest price anywhere. If you don't but if for this price, you are crazy. This late model Nikon Optiphot 150 microscope employs the new Nikon CF Infinity optical system. It is in truly excellent condition and yields some of the best viewing I have ever seen. CFplan 10xBD, CFplan 20xBD, CFplan 50xBD objectives on a MOTORIZED 5 position nose piece. Nikon CFWN 10x/20 eyepieces. B/D Vertical illuminator with iris aperture, pinhole, and field diaphragm, with ND filter. Upgraded 100 watt halogen illuminator is excellent. Mechanical xy 6x6 stage with large easy to control knobs. Built in 100 watt power supply with control knob in front. Available Nikon CFplan 150x EPI bright field objective $1500
Bausch & Lomb / Mitutoyo FS Trinocular Brightfield / Darkfield Metallurgical Microscope $7988 Now on sale $7388This late model Bausch & Lomb / Mitutoyo FS microscope is a real gem. It is like new. List new on this is $17K. Zeiss 10x25 plan adjustable eyepieces. Trinocular Mitutoyo wide field head with Javelin high resolution camera. Mitutoyo Finescope 1x - 2x Zoom body with vertical illuminator and aperture diaphragm. Mitutoyo objectives M Plan Apo 2x, M Plan Apo 10x, M Plan Apo 20x, and M Plan Apo SL 50x. 6x6 xy transmitted light stage. 150 watt Mitutoyo power supply for vertical illumination separately. Built in power supply for bright field / dark field illumination for both transmitted and reflected light. Lighting controlled by switches on side, 4 rheostat controls in front. Has course and fine focus with 2nd position fine focus under stage SOLD.
Olympus SZX-12 Research Stereo Zoom Microscope. Excellent condition with little use. The ultimate research scope for the discriminating researcher with top quality in mind..7x to 9x magnification. 30 degree observation tube. Fine focus. 10x widefield eyepieces. Plan FL lenses .3x and .5x. 2 position revolving nose piece. Beam Splitter. Photo Adapter. Universal boom stand. Olympus DP-11 Digital still camera system complete with boards. Sony CCD DXC 390 1/3" Video Camera System 800 lines complete with everything. Fostec 150 watt ring light.  This scope was $21k new just a couple of years ago. SOLD
Olympus Beta Metallurgical Microscope. $2388 Wonderful condition, a real beauty. 10x CHWK10x23 eyepieces, Mpl5x, Mpl10x, Mpl20x ,Mpl40xLWD, Mpl100x objectives. 6x6 flat top stage. Built 6v 20w halogen illuminator power supply with variable voltage. Vertical illuminator had aperture and field iris controls and placement for filters. Course and fine focus controls.
Olympus PM-10 Camera $449 It has been sitting on a shelf in the store room since new. It has been demo'ed a couple of times and is as new. With 2.5x photo eyepiece and adapter assembly. Compete assembly including adapter for Olympus trinocular microscopes. Fits BH etc...series trinocular microscopes. May be used on other makes of microscopes with a 25mm diameter photo port tube. Comes with shutter release cable.

OLYMPUS BH-2-BHT METALLURGICAL MICROSCOPE- $3488 Approximate age 8 years- Fully serviced. Excellent condition -Olympus binocular head with interpupillary and diopter adjustment-Olympus WHK-10X20L Eyepieces - Brightfield / Darkfield infinity vertical illuminator with aperture iris diaphragm- 6-volt 20watt infinitely adjustable intensity illuminator (2 – 8 volts)- 115vac 50/60Hz main power- Built in power supply- Olympus NeoSplan 5x, 10x, 20x, 50xDIC bright/darkfield objectives. Voltage adjust slide bar (illuminator intensity) on lower right side of base- 4x4 inch travel flat top ball bearing stage- Coaxial low right hand stage xy controls- Coaxial course/fine focus on both sides (2 micron graduated fine focus wheel on right side)- Precision Olympus 4 position ball bearing nosepiece - Z axis measurement bracket mounted to scope for measuring.



OLYMPUS BH-2-BHT METALLURGICAL MICROSCOPE- $3488 Approximate age 8 years- Fully serviced. Excellent condition -Olympus binocular head with interpupillary and diopter adjustment-Olympus WHK-10X20L Eyepieces - Brightfield / Darkfield infinity vertical illuminator with aperture iris diaphragm- 6-volt 20watt infinitely adjustable intensity illuminator (2 – 8 volts)- 115vac 50/60Hz main power- Built in power supply-  Olympus NeoSplan 10x, 20x, 50xDIC, 100x bright/darkfield objectives. Voltage adjust slide bar (illuminator intensity) on lower right side of base- 4x4 inch travel flat top ball bearing stage- Coaxial low right hand stage xy controls- Coaxial course/fine focus on both sides (2 micron graduated fine focus wheel on right side)- Precision Olympus 4 position ball bearing nosepiece - Z axis measurement bracket mounted to scope.



OLYMPUS BH-2-BHT METALLURGICAL MICROSCOPE- $3088 Approximate age 8 years- Fully Serviced - Excellent condition - Olympus binocular head with interpupillary and diopter adjustment-Olympus WHK-10X20L Eyepieces - Brightfield / Darkfield infinity vertical illuminator with aperture iris diaphragm- 6-volt 20watt infinitely adjustable intensity illuminator (2 – 8 volts)- 115vac 50/60Hz main power- Built in power supply- Olympus NeoSplan 5x, 10x, 20x, NeoDplan 80x bright/darkfield objectives. Voltage adjust slide bar (illuminator intensity) on right side of base- 4x4 inch travel flat top ball bearing stage- Coaxial low right hand stage xy controls- Coaxial course/fine focus on both sides (2 micron graduated fine focus wheel on right side)- Precision Olympus 4 position ball bearing nosepiece - Z axis measurement bracket mounted to scope for digital indicator for measuring.
Mitutoyo 40" Digital Electronic Height Gage $1088 in excellent condition. .0005"/.010mm resolution. Uses 3 AA batteries for operation. Has zero, preset, absolute, incremental, inch/metric functions. Excellent condition and ready for work. SOLD
SPI 20"bench center $369 in excellent "as new" condition. This a demo unit that was only out on the floor, never sold. Excellent condition with an extra set of uprights. Comers with 3 gage holders. A real gem!! True to center within .00015".
Brown and Sharp High Accuracy Height Master. $439 Reads directly in "tenths" (.0001") Unit is in excellent condition. Block stack is standard 12" with 1" of travel. Staggered block arrangement with digital 1 thousandth reading (.001")
Mitutoyo PH350 12" Optical Comparator. $3788 Horizontal light path. This unit comes on a heavy duty 4 caster roll cart with storage shelf and drawer. The PH350 has a 1 micron/50 millionths digital with many functions. Has 10x, 20x and 50x lens sets with standard and surface illumination. This unit has been full serviced and is ready for work. Large stage with quick position feature. Comes with a complete set of attachments including vertical rotatable glass stage, swivel precision vise, post mount and a set of precision adjustable centers.
Mitutoyo PJ 250 10" Optical Comparator. $2488 Vertical light path. High/low lighting. Precision 2x2 Mitutoyo stage with digital Mitutoyo micrometer heads with 2" travel. Micrometer heads have speed handle, inch/metric, zero, data output, 1 micron, 50 millionths reading capability. An excellent unit with great ease of use and excellent accuracy. I can easily repeat 1/10th(.0001") measurements with this unit. Lens assembly is 10x. Top glare hood is retractable.
